Dental Milling Machine P5 - Up3d
Features:
- Automation: Automatic Calibration, tool changer and calculation of tools lifetime.
- Led Milling Progress Bar. Displaying the milling progress of P53 can reduce personnel inspection time and improve efficiency.
90° Milling. It is convenient for the embrasure processing of the anterior teeth, making the finished teeth closer to the designed teeth, and the shape is more beautiful and complete.
Product Description
P53 is a dry-cutting device developed by Cloud A Technology that combines intelligent control system and one-piece structure perfectly, supporting cutting of various dental materials such as zirconia, resin, wax block and PMMA, with powerful functions such as automatic calibration, tool life detection and breakpoint renewal, etc. The device is intelligent, easy to process and has excellent results, further helping denture processing factories to scale up digital production.
Specifications
- Brand : Up3D
- Model : P53
- Dimension : 718*443*628 （ mm ）
- Weight : 87 kg
- Input Voltage : AC 200-240V, 50-60 Hz
- Max Power : 1.1 KW
- Spindle Power : 0.35 KW (max)
- Axis : 5 -axis simultaneous motion
- Milling range: X/Y/Z:170/215/105 mm A: +/-30° B:360°
- Milling mode: Dry milling
- Max rotate speed: 30,000 rpm
- Max feed rate: 3000 mm/min
- Tool quantity: 11
- Tools changing : Automatic (Air pressure > 0.5MPa)
- Spindle cooling : Air cooling
- Milling materials : Zirconia, Wax, PMMA, PEEK and soft material.
- Milling time :
- Coping : Zirconia - 10 min; Wax - 4.5 min
- Crown: Zirconia - 13 min; Wax - 5.5 min
- Tools diameter : 2+1+0.6(Ø4 calibration bur)
- Disc specification: Round disc with Ø 98,30mm max for thickness
- Spindle claming diameter: Ø4.0mm
- CAM supported: UPCAM and Millbox
- Data transmission: Network interface
Documentation
Brochure
Video
- Up3D Milling Mahcine P53 Introduction Video
